Orizontal CNC fraisage machin
Kalite orizontal Spindle, BT40 oswa BT50 Spindle ka chwazi dapre demann pwosesis materyo.
Avantaj aktyèl yo nan machin nan fraisage CNC orizontal yo se kapasite segondè presizyon koupe li yo, ki pèmèt pou fòm trè egzat ak fraisage nan materyo. Avèk teknoloji avanse CNC, machin sa a se tou trè otomatize, diminye bezwen an pou travay manyèl ak ogmante efikasite. Anplis de sa, konfigirasyon orizontal machin nan pèmèt aksè fasil ak manyablite, fè li ideyal pou itilize nan yon varyete anviwònman endistriyèl. An jeneral, machin fraisage CNC orizontal la ofri solisyon machin egzak ak efikas ki ka ede biznis amelyore pwodiktivite ak bon jan kalite nan pwosesis fabrikasyon yo.
MODÈL HMC500 HMC630
Kalite orizontal Spindle, BT40 oswa BT50 Spindle ka chwazi dapre demann pwosesis materyo.
Kontwolè diferan tankou:
Siemens, FANUC, SYNTEC, Mitsubishi, FOGOR, Heidenhain, TAIWAN LNC cnc kontwolè ka chwazi
ATC/Otomatik chanje zouti ka chwazi selon kondisyon pwosesis aktyèl la.
3 aks, 4 aks, 5 aks opsyonèl
LINEAR GUIDE RAILS SERIES VMC Product Specification
|
Atik |
Inite |
MHMC50A |
MHMC50B |
MHMC63 |
MHMC80 |
MHMC100 |
MHMC80T |
|
Vwayaje |
|||||||
|
Vwayaj X Aks |
mm |
700 |
750 |
1050 |
1300 |
1600 |
2500 |
|
Vwayaj aks Y |
mm |
650 |
750 |
1000 |
1200 |
1300 |
1200 |
|
Z aks vwayaj |
mm |
600 |
750 |
1000 |
1200 |
1300 |
1300 |
|
Spindle |
|||||||
|
Spd. Sant pou tab la |
mm |
50-700 |
50-800 |
50-1050 |
75-1275 |
75-1375 |
120-1320 |
|
Spd.Nose pou sant tab la |
mm |
200-800 |
100-850 |
80-1080 |
150-1350 |
250-1550 |
350-1650 |
|
Spindle Taper |
|
BT50 |
BT50 |
BT50 |
BT50 |
BT50 |
BT50 |
|
Vitès koton |
RPM |
10000 oswa 6000 |
10000 oswa 6000 |
6000 |
6000 |
6000 |
6000 |
|
Motè Spindle |
KW |
FANUC 11/18.5 |
FANUC 11/18.5 |
FANUC 15/18.5 |
FANUC 15/18.5 |
FANUC 15/18.5 |
FANUC 22/26 |
|
Spindle Max.Torque |
N.m |
307/442 |
307/442 |
525/634 |
525/634 |
525/634 |
560/800 |
|
Rotary tab travay (aks B) |
|||||||
|
Tablo travay (LxW) |
mm |
500x500 |
500x500 |
630x630 |
800x800 |
1000x1000 |
800x800 |
|
Min. Degre |
Deg |
1 degre /0.001 degre |
1 degre /0.001 degre |
1 degre /0.001 degre |
1 degre /0.001 degre |
1 degre /0.001 degre |
1 degre /0.001 degre |
|
Baz twou Dia. |
mm |
Φ50H7 |
Φ50H7 |
Φ55H7 |
Φ55H7 |
Φ55H7 |
Φ50H7 |
|
Max.Chajman |
KG |
500 |
500 |
1200 |
1600 |
2000 |
2500 |
|
Divize Presizyon |
sec |
± 4 degre |
± 4 degre |
± 4 degre |
± 4 degre |
± 4 degre |
± 4 degre |
|
Repete Presizyon |
sec |
± 2 degre |
± 2 degre |
± 2 degre |
± 2 degre |
± 2 degre |
± 2 degre |
|
Worktable No. |
|
2 |
2 |
2 |
2 |
2 |
1 |
|
Feedrate |
|||||||
|
Rapid vitès |
m/min |
24/24/24 |
24/24/24 |
24/24/24 |
24/24/24 |
24/24/24 |
12/12/12 |
|
Koupe Feedrate |
mm/min |
1-10000 |
1-10000 |
1-10000 |
1-10000 |
1-10000 |
1-7000 |
|
ATC |
|||||||
|
ATC No. |
T |
24(30/40/60) |
24(30/40/60) |
30(40/60) |
30(40/60) |
30(40/60) |
40(60) |
|
Presizyon |
|||||||
|
Pozisyon presizyon |
mm |
±0.01 |
±0.01 |
±0.01 |
±0.01 |
±0.01 |
±0.01 |
|
Repete Presizyon |
mm |
±0.005 |
±0.005 |
±0.005 |
±0.005 |
±0.005 |
±0.005 |
|
Lòt moun |
|||||||
|
Presyon lè |
Kgf/c㎡ |
6 |
6 |
6 |
6 |
6 |
6 |
|
Machin Wight |
KG |
12000 |
12000 |
16500 |
22000 |
22000 |
26500 |
|
Anprint |
mm |
5300x3645 |
5000x3310 |
5845x3815 |
6045x4030 |
6145x4330 |
4530x6450 |
|
Wotè machin |
mm |
3035 |
3200 |
3465 |
3665 |
3765 |
4470 |
Baj popilè: orizontal cnc fraisage machin
